22/03/2022 – Wafios theme for “wire” and “Tube” 2022

“Future Forming Technology”

Finally: After several years, the “wire” and “Tube” show will once again take place live on site in Düsseldorf, Germany. “Future Forming Technology“ – This year's theme of the Reutlingen-based forming expert Wafios defines the company’s exhibition program.


Wafios “FUL 226”. © Wafios


Wafios “ZO 26”. © Wafios

Show all images

The focus is on trendsetting high-speed technologies that enable productivity leaps in manufacturing, as well as revolutionary production processes and automation solutions. New fields of application as well as digital services for intelligent maintenance processes complete the exhibition program. The so far largest exhibition program by Wafiosand their subsidiaries awaits visitors on more than 1,600m² of exhibition space in hall 10 F22/F40 (wire) and in hall 5 A21/A22 (Tube).

Minimum cycle times with maximum flexibility and modularity!
For the first time, the new transfer and bending technology will be presented in combination with the compression spring coiler “FUL 26+”.
The recently developed transfer and bending unit enables parallel forming operations over several stations and thus considerably reduces the cycle times per part. Stations are based on a modular concept that allows them to be adjusted to the most different applications and to be connected with the according spring, wire or tube bending machines. The transfer and bending unit will be presented at the “wire” show in combination with the spring coiling machine “FUL 26+” for the production of extended loop springs that are often used in the automotive and e-mobility sector.

Productivity leaps with high-speed technology for the production of springs and wire parts
The “4speed”-technology celebrates its international world premiere. As of late, "4speed" stands for Wafiosdevelopments that have been designed for highest production outputs. The new “FUL 26+ 4speed” and “FUL 36+ 4speed” are –in their ultimate expansion stage –the fastest spring coiling machines in the world. They produce compression springs at a wire infeed speed of up to 600m/min.
The new high-speed wire bending machines make their international trade fair debut in Düsseldorf and set new standards in terms of speed, productivity and quality. The Wafios “BM 43 HS” will be exhibited as stand-alone machine and the “BM 36 HS” will be presented for the first time together with a handling robot that is fully integrated in the Wafios control system “WPS 3.2 Easy Way”.

Trendsetting: Coldforming of up to 22 mm high-strength spring steel wire - International world premiere of the “FUL 226”
With the new “FUL 226” it is now possible to cold-form 22mm wire at 2,000N/mm². All the familiar cold-forming advantages known from “FUL” machines, like e.g. more freedom of geometry, the use of camera technology and flexible programming possibilities, are now also available for the upper wire diameter range. New markets in the e-mobility, hybrid vehicle and light truck sector are opened up. The 40-ton spring coiling machine will be presented digitally in Düsseldorf.

Automated production solutions from Wafiosintegrated in one programming system
Wafios will present new automation solutions, like loading units, feeding systems and production cell solutions, for all fields of application.
The programming system “WPS 3.2 Easy Way” stays a decisive step ahead by integrating previously independent systems, like a handling robot or other processing units, completely into the machine’s control system.
The wire bending machine “BM 60” and the servo-electric header “RU 60” from WafiosTube Automation will show how this integration works. The combination of 60-tons of forming force and newly developed tool system offers new possibilities in the production of wire parts that require an endworking process on one of their ends.

Trendsetting e-mobility technology for the first time at the “wire” show
Wafios will present the “FMU 40E”, with a handling robot completely integrated in the machine's control system, for the production of stator hairpins. Other applications, like e.g. busbars and cooling lines used in the e-mobility industry, can be found at all Wafiosbooths in Düsseldorf.

Keeping maintenance processes intelligently under control –“Digital Services”by Wafios
Wafios' intelligent maintenance software “connectavo –The Digital Assistant for Machines and Machinery Systems”will debut at the fair.
Wafios also presents for the first time a standardized, open system for the complete networking of machines and machinery systems.

Numerous other machine premieres in Düsseldorf - Wafios presents the most extensive exhibition program ever
Wafios “G450” spring end grinding machine with new robot feeding system. A “Smart Machine” connected with the trendsetting technology database “iQsmartgrind” and a new loading unit.

Consistent enhancement of all machine product families
The Wafios “SNA 26” for the production of wave springs and rings, closes the gap in the wire diameter ranges of the “SNA 16” and “SNA 36”.
After the successful market introduction of the legendary “ZO”-series in 2021, Wafiosfinally presents the long-awaited “ZO 16” for smaller wire diameters.
Wafios“BMS 50” multiple-head wire bending machine for wire diameters up to 10mm will also debut at the fair. The “BMS” will be exhibited together with a CNC-controlled chamfering device for chamfering both ends of rods.
From the straightening area, the Wafiosstraightening machine “R 36” for straightening smooth rods will be presented together with “iQmstraight” for measuring the straightness of rods. It features a newly developed, adjustable rotor for automatic readjustment when processing rods that are not within the straightness tolerance.

Attractive service offers and innovative tool solutions complete the broad exhibition program
The new retrofit solution for the classic “FMU 2” machine will also debut at the fair. From the wire bending area, Wafiospresents the new, modular set of tools “MBS” for the most diverse applications. From the spring coiling area, the focus will be on new coating solutions for tools of the “FUL”-series.

Wafios Umformtechnik presents PTS, the new "Pneumatic Transport System" at the cold former “HC 15”
The newly developed PTS ensures resource-conserving ejection of parts,mixing of parts during product changes is effectively avoided. Parts leave the machine virtually free from oil,good parts are automatically separated from rejects by a sorting device.

EWMenn, the specialist for thread and profile rolling machines will present their new, digital machine assistant
“iQ – Setup Assist”: The easy-to-use and product-specific set-up help that can be operated by the push of a button; and “iQ – OEE Monitor”: The machine data acquisition assistant for process evaluation.
From their current range of machines, EWMenn will present the “AF 141” high-speed thread and profile rolling machines with flat dies.

"Future Forming Technology" theme also reflected in the program of the Wafios “Tube” booth
A revolutionary production technique for the flexible bending of large and small batches of plastic tubes opens up new fields of application - World premiere of the Wafios “HotBend 35”.
The new “RU 12” compact from WafiosTube Automation ensures maximum flexibility in tube end forming operations. Endforming operations with short cycle times. The machine will be exhibited at the show for flexible use, both as standalone and cell solution.

For their complete exhibition program under the motto “Future Forming Technology” go to www.wireandtube.wafios.com. Arrange a meeting with themat the fair online.

wire 2022, hall 10 booth F 22/40
Tube 2022, hall 5 booth A 21/22
