Servo hydraulic bar stop

Hatebur has developed a new system for cutting forgings. A servo-hydraulic stop ensures the quality of the sheared sections and makes post-processings unnessesary. The manufacturer offers the technology on several machine types.


© Hatebur


© Hatebur

Show all images

It was a ground-breaking development, says Swiss machine tool builder Hatebur. The servo hydraulic bar stop is designed to make metal forming manufacturers more productive. “The servo hydraulic bar stop optimises the shear surface and boosts the quality of forged parts. That facilitates and speeds up the quality control and can make post processing obsolete. The technology enhances the productivity of manufacturers”, explains Hatebur CEO Thomas Christoffel. The Swiss enterprise, a global leader in high-quality forming machines and tools, will offer the new technology on a variety of machine types.

The innovation targets the first step of the metal forming process: Before the parts are formed in the various forming stations, the inductively heated steel bars need to be sheared off with highest precision. In the past, the shearing process led to a slight tilting and an oblique position of the sheared part. “Besides that, the shearing process changed into a tearing process towards the end, resulting in a so-called shearing break-out”, reports Mr. Christoffel. Sometimes scuffing was generated at the sheared surface, which needed to be removed from the finished forged parts by sandblasting. If these scuffing were pressed onto each other during the forming process, the producers needed to post process the parts by metal cutting.

Thanks to the innovative servo hydraulic bar stop, the tilting and oblique positioning can be drastically reduced, and the surfaces are now virtually parallel. “Now, scuffing is rarely generated, and thus is practically never pressed into folds”, explains Mihai Vulcan, an employee of Strategic Projects at Hatebur. Since 2017, Hatebur has been testing the technology thoroughly in a development partnership with a leading European automotive supplier. It was tested on a Hatebur “Hotmatic HM75 XL”. The results were outstanding: The scuffing on the shearing surface was able to be minimised from 20% of the surface to just 1%. The new bar stop technology also minimised or eliminated the shearing break-out. This resulted in a considerable quality improvement of the parts, facilitating and speeding up the visual control after the sandblasting. Thomas Christoffel: “If the quality control can be accelerated by only half a second per part, the technology already brings a real benefit to our customers.”

Minimised scuffing

The shearing process is incredibly fast: Depending on the bar diameter and the machine speed, it takes between 60 and 100 milliseconds. Only a servo hydraulic drive can offer the necessary dynamics and power density in a small space. The inter-divisional project team of Hatebur, led by Mihai Vulcan, applied an alternating position and force control. Should at the end of the in-feed movement the bar stop deviate from its target position even by only a few hundredths of a millimetre, the position of the bar stop will be immediately adjusted via the servo valve. “This position control allows us to keep the actual distance between the blade and the bar stop constant during the whole shearing process”, emphasises Mihai Vulcan. After the shearing process starts, the control shifts to a force control with position monitoring. Throughout the process, the integrated measuring technology records the process data. When deviations are recognised, the automatic control adjusts imbalances immediately, ensuring an optimised surface quality.

Hatebur is synonymous with hot and cold massive forming, service, precision tools and process engineering. Founded in Switzerland in 1930, the company works with an international network of fully owned subsidiaries and sales partners to guarantee high-quality products and services that are never far away from its customers. After an in-depth consultation and design process, Hatebur offers a machining solution for producing high volumes of precision metal parts that meets the customer's needs and requirements perfectly. Whether for the automotive, rolling bearing, aviation or fastener industry, Hatebur create solutions that offer maximum performance and efficiency.

Hatebur Umformmaschinen AG

 General-Guisan-Strasse 21

 4153 Reinach BL1/Switzerland

 Contact person is Mr. Thomas Christoffel

 Tel.: +41 61 7162111
